Why the Humble Hook Is the Perfect First Project

Of all the things you can make at the anvil, the simple iron hook gives you the most for the least. It takes one length of round bar, a couple of heats and perhaps forty minutes at the forge. Yet packed into those forty minutes are three of the skills every blacksmith leans on: drawing out, bending and punching. Master those and you can move on to pokers, tongs, gate latches and scrollwork with real confidence. Make a mess of them and you have learned something valuable on a piece of steel that cost you pennies.

This guide assumes a gas or solid fuel forge, a solid anvil and a few basic hand tools. If your first hook comes out a little lopsided, that is entirely normal — keep it, hang it up, and compare it with your tenth.

Choosing Your Stock and Setting Up

Start with 10mm mild steel round bar, cut to roughly 200mm. Mild steel is forgiving, cheap and easy to find, and 10mm is thick enough to hold heat while you work it but thin enough to move under a moderate hammer. Avoid anything galvanised, painted or of unknown origin — zinc fumes are genuinely nasty, and mystery steel behaves unpredictably in the fire.

Before you light anything, get your kit together on the bench:

• A 1kg to 1.5kg hammer — a cross-peen or ball-peen gives you both a flat face and a shaping end
• Tongs that grip 10mm bar comfortably without slipping
• A hot cut or hacksaw for cutting to length
• A wire brush, a coarse file and a length of emery cloth
• A hot punch around 8mm in diameter, plus a bolster or access to the pritchel hole
• Beeswax, linseed oil or a good paste wax for finishing
• Eye protection, a leather apron and gloves for the tong hand

Bring the fire up cleanly and let it settle. You want a bright orange heat — roughly 1,100°C — for drawing out. If the steel throws sparks and turns white, you have burnt it and the metal will crumble under the hammer. Better to take two moderate heats than one ruined one.

Drawing Out the Taper

Take your first heat on the last 70mm of one end only. Hold the bar flat on the anvil with the hot end overhanging the far edge, and strike with overlapping blows using the flat face of the hammer, working from the shoulder of the taper towards the tip. Rotate the bar a quarter turn every few blows so you are working all four faces evenly. This is how you keep the taper round rather than flattened into a blade.

Aim to reduce that 70mm to a smooth, even taper finishing around 4mm across. Then square off the final 15mm with light blows, and round the very tip so it is blunt rather than needle-sharp. Put it back in the fire the moment it drops below a dull red — cold steel does not move, it only damages your elbow and your anvil's edges.

Bending the Hook and Shaping the Scroll

Once the taper is formed, bring the whole hook end to a good orange and take it to the horn of the anvil. Lay the bar across the horn and hammer the tapered section around it, working steadily from the shoulder outwards. You are looking for a smooth, even C-curve, not a kink. If you try to bend it too fast in one place, that is exactly what you will get.

For a decorative finish, take a fresh heat on the last 25mm and curl it into a small scroll using the tip of the horn, tapping it round in stages. A tight, deliberate curl at the tip lifts the whole piece from "functional" to "made by someone who cares". Alternatively, bend the hook over the edge of a vice for a sharper, more workmanlike curve. Both are traditional; pick the style that suits where the hook will hang.

Punching the Eye

Now for the top end. Bring the last 40mm to a bright orange heat and lay it flat across the pritchel hole. Set your punch roughly 20mm down from the end and drive it in with firm, straight blows, stopping when you feel it bite through to about halfway. Flip the bar and punch from the other side until the holes meet. Keep the punch cool by dipping it in water every few strikes — a hot punch mushrooms at the tip and jams in the hole.

Once the hole is through, drive a tapered drift through it to tidy the sides and open it to a clean, round eye. Work quickly while the steel is still hot, then leave the hook to cool slowly in air. Do not quench mild steel straight from the forge unless you want it harder than your drill bits can cope with.

Finishing and Hanging Your Hook

Finishing is where a plain hook starts to look like a proper piece of ironwork. Reheat the whole hook to a black heat — just below visible red — and scrub it vigorously with a wire brush until the scale lifts and the surface turns a warm, even grey. This is the moment to clean up any hammer marks you do not like with a file, though most smiths leave a few as a signature.

While the metal is still warm enough to be uncomfortable to hold, rub on beeswax or brush over a little linseed oil. The wax melts into the surface and gives a soft, dark sheen that will deepen with age. Buff off the excess with a cloth and leave it to cool properly. Then find a nail, hang it up, and start planning your next one — a pair of hooks makes a far better coat rack than a single one ever will, and by then your hammer blows will already be landing straighter.
